Introduction: The Heart of Your Shredding Operation

In the demanding world of size reduction, whether you're processing plastic bottles, wooden pallets, or automotive scrap, your double shaft shredder is only as effective as the blades at its core. Selecting the wrong blades can lead to catastrophic downtime, poor output quality, and soaring operational costs. The right choice, however, transforms your operation, delivering maximum efficiency, superior particle size, and a rapid return on investment. This comprehensive guide is designed to demystify the process of choosing the perfect double shaft shredder blades for plastic, wood, and metal. We will delve deep into the critical aspects of blade materials—comparing industry standards like SKD-11, D2, and H13—as well as tooth design and thickness. As a specialist manufacturer focused exclusively on single and double shaft shredder blades, ShengAo brings you this expert analysis to ensure your shredding process is nothing short of exceptional.

Blade Materials Decoded: SKD-11, D2, H13, and More

The material of your shredder blades is the first and most critical determinant of performance and longevity. It defines the blade's ability to resist wear, absorb impact, and maintain a sharp edge. Let's break down the most common high-performance steels used in Industrial Shredder Blades.

SKD-11 (AISI D2 Equivalent): This is a high-carbon, high-chromium cold work tool steel. It is renowned for its excellent wear resistance and good toughness after heat treatment. SKD-11 blades can achieve a high hardness (HRC 58-62), making them a superb all-rounder, particularly effective for shredding mixed materials, plastics, and non-ferrous metals. They offer a great balance between durability and cost-effectiveness.

D2 Tool Steel: Very similar to SKD-11, D2 is a staple in the shredding industry. It provides outstanding abrasion resistance, second only to tungsten carbide in many applications. D2 shredder blades are ideal for processing highly abrasive materials like fiber-reinforced plastics, e-waste, and wood with contaminants.

H13 Hot Work Tool Steel: Where H13 excels is in its combination of high toughness and good resistance to thermal fatigue. While it may not have the pure wear resistance of D2, it is less brittle and can withstand significant impact shocks. This makes H13 blades the preferred choice for applications involving high-strength metals or where the risk of encountering uncrushables (like occasional tool steel) is high.

Cr12MoV: This is another type of cold work die steel, offering good hardenability, high wear resistance, and excellent stability after heat treatment. It is a cost-effective alternative for less severe applications but still provides a significant performance upgrade over standard carbon steels.

Choosing the Right Material:

• For Abrasion Resistance (Plastics, Wood, E-Waste): SKD-11/D2 is your best bet.
• For Impact Resistance (Metals, Dense Wood, Mixed Waste): H13 provides the necessary toughness.
• For a Balanced Budget & Performance: Cr12MoV offers a solid solution.

Choosing Blades for Plastic Shredding

Shredding plastic presents a unique challenge: the material is not particularly hard, but it can be extremely abrasive, especially when filled with glass fibers, minerals, or contaminated with sand. The primary goal is a clean cut that produces uniform flakes for optimal washing and recycling.

Recommended Material: SKD-11 blade or D2 steel is typically the ideal choice. Their superior wear resistance ensures a long life even when processing PET bottles, HDPE containers, nylon, and ABS. For the most abrasive streams, such as fiberglass-reinforced plastics, a hardened shredder blade made from D2 is essential.

Tooth Design: A straight or slightly slanted "ripper" tooth design is often preferred. This geometry shears the plastic rather than hacking at it, resulting in a cleaner cut, less fines generation, and lower energy consumption. The sharper edge is more efficient at slicing through ductile plastic materials.

Thickness: Blade thickness for plastic is generally on the lighter side (e.g., 20-40mm, depending on machine size), as the cutting forces are lower than with metal or dense wood. This also helps in achieving a sharper cutting angle.

ShengAo Solution: Our Shredder blades for plastic recycling are precision-engineered from premium SKD-11 and D2 steels, heat-treated to HRC 60-62 to maximize service life against abrasive materials.

Choosing Blades for Wood Shredding

Wood shredding involves dealing with a fibrous, often unpredictable material that can contain nails, dirt, and stones. The key requirements are high toughness to handle impacts and good wear resistance to manage the abrasive nature of wood fibers and potential contaminants.

Recommended Material: H13 tool steel is frequently the top choice for Blades for wood waste shredding due to its exceptional toughness. For clean wood and pallets, a high-quality D2 blade can also deliver excellent performance. The choice often depends on the contamination level.

Tooth Design: A "hook" or "claw" tooth design is highly effective for wood. This aggressive geometry grabs and pulls the material into the cutting zone, preventing kickbacks and ensuring efficient processing of large, irregular pieces like stumps and root balls.

Thickness: Wood shredder blades need to be robust. Expect thicknesses in the 30-50mm range to provide the necessary mass and strength to absorb the high-torque, high-impact forces encountered when breaking down timber.

ShengAo Solution: We offer custom-hardened blades with claw-type geometries, made from H13 or D2, designed to withstand the punishing environment of wood and biomass shredding, providing Long life shredder blades even in the toughest conditions.

Choosing Blades for Metal Shredding

Metal is the ultimate test for any shredder blade. The forces involved are immense, and the primary failure mode is not wear, but chipping and catastrophic breakage from impact. Toughness is the single most important property here.

Recommended Material: H13 tool steel is the undisputed champion for metal scrap shredder blades. Its exceptional impact toughness allows it to handle the shock loads from shearing and tearing through steel sheets, aluminum blocks, and white goods (appliances) without failing.

Tooth Design: The tooth design for metal is often a robust, low-profile hook or a specialized "square" tooth. The focus is on strength over sharpness. A stronger, more obtuse cutting angle on the tooth prevents the tip from fracturing under extreme pressure.

Thickness: This is where blades are at their heaviest. Metal shredder blades can be 50mm thick or more, providing the immense structural integrity required to transmit the huge forces from the rotor to the material without bending or breaking.

ShengAo Solution: Our heavy-duty metal shredding blades are forged from premium H13 steel and heat-treated using a proprietary process that maximizes core toughness while maintaining a hard, wear-resistant surface. They are the definitive choice for demanding metal scrap shredder blades applications.

Tooth Design & Thickness: Geometry Matters

While material is king, the geometry of the blade is what executes the cut. The tooth design and overall thickness work in concert with the material to define the shredding action.

Common Tooth Designs:

• Straight/Ripper Tooth: Best for shearing and slicing. Ideal for plastics, rubber, and paper.
• Hook/Claw Tooth: Excellent for grabbing and tearing. Perfect for wood, MSW (Municipal Solid Waste), and loose materials.
• Spiral Claw Tooth: Provides a progressive, quieter cut with lower RPMs and reduced energy consumption. Excellent for a wide range of materials.

Blade Thickness: Thickness correlates directly with the shear force the blade can transmit.

• Thin Blades (20-30mm): Used for low-torque, high-speed slicing of soft materials like film and fiber.
• Medium Blades (30-40mm): The most common range, suitable for plastics, wood pallets, and general-purpose recycling.
• Thick Blades (40mm+): Reserved for high-torque, high-shock applications like metal shredding and dense wood.

Selecting the wrong geometry or thickness for your material will force the machine to work harder, leading to premature wear, motor strain, and poor particle size control.

Why Choose ShengAo Double Shaft Shredder Blades?

At ShengAo, we don't just sell blades; we provide engineered solutions. Our singular focus on manufacturing top-tier single and double shaft shredder blades allows us to master the craft. Here’s what sets us apart:

1. Premium Materials: We source only the highest grades of SKD-11, D2, and H13 steel, ensuring a perfect foundation for every blade.

2. Precision Heat Treatment: Our in-house heat treatment facility allows for meticulous control over the hardening and tempering process. This results in blades with a hard, wear-resistant surface and a tough, shock-absorbing core—the best of both worlds.

3. Expert OEM Manufacturing: We are a leading Custom shredder blades OEM partner. We don't just make standard sizes; we custom-engineer blades to your exact specifications, drawings, and machine models, ensuring a perfect fit and optimal performance.

4. Unbeatable Value: By controlling the entire manufacturing process, we eliminate middlemen and offer Shredder blades factory price without compromising on quality. Our blades deliver a lower cost-per-ton, providing significant savings over their extended service life.

Upgrade your operation with genuine ShengAo performance. Explore our range and discover the ShengAo difference.
English: Industrial Shredder Blades (Black Friday Sale Ongoing!)
日本語 (Japanese): 産業用シュレッダーブレード (Industrial Shredder Blades)
Русский (Russian): Промышленные ножи для шредеров (Industrial Knives for Shredders)

Click to Play Video

ShengAo Blades: Universal Compatibility with Top Shredder Brands

A common concern is whether aftermarket blades will fit and perform as well as OEM parts. At ShengAo, our core competency is Custom shredder blades OEM manufacturing. We engineer our blades to be direct replacements, ensuring seamless integration and superior performance in a wide range of machinery from the world's leading manufacturers. Our blades are designed to adapt to and enhance the performance of the following brands (and many more):

Metso: Our robust blades are engineered to match the high-performance standards of Metso shredders, often used in demanding aggregate and mining recycling applications.

Vecoplan: As a leader in wood and waste shredding technology, Vecoplan machines demand durable blades. Our H13 and D2 blades are perfectly suited for their high-torque, high-throughput systems.

UNTHA: We provide precision-engineered blades that meet the exacting standards of UNTHA's sophisticated shredding systems, known for their reliability in industrial and hazardous waste processing.

WEIMA: For WEIMA's extensive range of single and double shaft shredders, we offer customized blade sets that deliver the clean, consistent cut required for plastics, wood, and paper.

Genox Recycling: Our blades are compatible with Genox shredders, providing the wear resistance needed for challenging plastic and e-waste streams.

Harden Machinery: A key player in the global market, Harden shredders benefit from our heavy-duty blade designs, particularly in plastic recycling and MSW processing lines.

GEP ECOTECH: We supply custom-fit blades for GEP ECOTECH's smart and efficient shredders, ensuring optimal performance in solid waste and resource recovery operations.

Maxin India Machinery: Our blades are designed to work seamlessly with Maxin's shredders, which are widely used for recycling plastic, metal, and organic waste.

Hammel: For the powerful primary and secondary shredding action of Hammel machines, our impact-resistant H13 blades are the ideal choice for processing demolition wood and mixed metals.

Arjes: We offer robust blade solutions for Arjes' slow-speed, high-torque shredders, which are perfect for processing difficult materials like construction waste and green waste.

Stiler: Our custom manufacturing service ensures a perfect fit for Stiler shredders, providing reliable performance in various recycling sectors.

Olnova: We provide efficient and durable blade sets for Olnova's range of recycling machinery, supporting their focus on plastic and rubber recycling solutions.

Final Thoughts: Cut Your Costs, Not Your Efficiency

Selecting the right double shaft shredder blades is a technical decision with direct financial consequences. By understanding the interplay between material composition, tooth geometry, and blade thickness for your specific application—be it plastic, wood, or metal—you can unlock new levels of productivity and profitability. Don't let inferior blades be the weakest link in your recycling chain.

Invest in blades engineered for performance and built to last. Invest in ShengAo.

Ready to optimize your shredding operation? Contact our technical team today for a free consultation and quote on custom-built double shaft shredder blades that will redefine your expectations for durability and output quality.
